PCD Turning Insert – VCMT080202SE KPD001 Zamów teraz

Opis

Opis:

PCD Turning Insert VCMT080202SE KPD001

Cecha szcz.:

RE (GTC – Corner radius): 0.2 mm
LE (GTC – Cutting edge effective length): 1.4 mm
Corner radius (RE): 2
S (GTC – Insert thickness): 2.38 mm
IFS (GTC – Insert mounting style code): 3
IC (GTC – Inscribed circle diameter): 4.76 mm
AN (GTC – Clearance angle major): 7 Degree
L (GTC – Cutting edge length): 8.298 mm
EPSR (GTC – Insert included angle): 35 Degree
Size: 802
TCE (GTC – Tipped cutting edge code): A
Grade: KPD001
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Chip breaker: SE
Description: VCMT
