PCD Turning Insert – VBMT110301SE KPD001 Kup online

Opis

Opis:

PCD Turning Insert VBMT110301SE KPD001

Cecha szcz.:

RE (GTC – Corner radius): 0.1 mm
Corner radius (RE): 1
LE (GTC – Cutting edge effective length): 2.5 mm
IFS (GTC – Insert mounting style code): 3
S (GTC – Insert thickness): 3.18 mm
AN (GTC – Clearance angle major): 5 Degree
IC (GTC – Inscribed circle diameter): 6.35 mm
L (GTC – Cutting edge length): 11.088 mm
EPSR (GTC – Insert included angle): 35 Degree
Size: 1103
TCE (GTC – Tipped cutting edge code): A
Grade: KPD001
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Chip breaker: SE
Description: VBMT
