Opis
Wykonanie:
- Operating and display units with satin chrome finish
- Dial comparator is integrated in frame
- Adjustable tolerance markers
- Chrome plated steel frame, heat insulated
- Retraction of the movable anvil ensures maximum wear resistance
- Spindle and anvil are carbide-tipped
- Stainless spindle is hardened throughout and ground
- Locking device
- Constant measuring force
Opis:
Micromar 40 FC vernier micrometer
- Factory standard measuring range: 25 – 50 mm
- cale graduation (µm): 1 µm
Scope of delivery: Instruction manual, case
Cecha szcz.:
- Dial colour: White
- Product type: 40 FC
- Measuring range: 25 – 50 mm
- Dimension a in mm: 174 mm
- Dimension b in mm: 125 mm
- Dimension d in mm: 85 mm
- Dimension e in mm: 56 mm
- Dimension c in mm: 30 mm
- Measuring force: 9 N
- Measuring force (text): 9
- Spindle diameter_mm: 7.5 mm
- Error limit_µm: 2 µm
- Error limit Ge (µm): 1 µm
- Parallelism deviation in µm: 1 µm
- Scale graduation (µm): 1 µm
- Spindle pitch_mm: 0.5 mm
- Flatness deviation in µm: 0.2 µm
Norma:
Factory standard
