Opis
Wykonanie:
- Threaded connection for changing the measuring head
- Self-centering measuring head consists of 3 anvils (offset 3 x 120°)
- Anvils from 12 mm are carbide tipped
- From 12 mm the anvils can be used to measure the bottom of a bore
- From 40 mm all measuring heads are made from aluminium to reduce weight
- Measuring value indication is always easy to read when using an electronic dial indicator with a rotatable display
Opis:
Self-centring internal measuring pistol Micromar 844 A
- Factory standard measuring range: 70 – 85mm
Scope of delivery: without display unit, basic unit 844 Ag, measuring head 44 Ak, operating instructions, case
Cecha szcz.:
- Calibration type: Uncalibrated
- Measuring range: 2.75 – 3.35″
- Remarks Error limit: ; With complete contact of the measuring probes ; Does not take the transducer into account ;
- Measuring depth with extension: 247 mm
- Dimension d in mm: 97 mm
- Measuring depth: 97 mm
- Dimension b in mm: 23 mm
- Dimension c in mm: 7 mm
- Error limit_µm: 4 µm
Norma:
Factory standard
