Turning Toolholder – PTLNR1620JX-16FF Wysoka jakość

Opis

Opis:

Turning Toolholder PTLNR1620JX-16FF

Cecha szcz.:

GAMO (GTC – Rake angle orthogonal): -6 Degree
LAMS (GTC – Inclination angle): -6 Degree
AN (GTC – Clearance angle major, Pos. A): 0 Degree
CNSC (GTC – Coolant entry style code): 0
CXSC (GTC – Coolant exit style code): 0
RE (GTC – Corner radius, Pos. A): 0.8 mm
S (GTC – Insert thickness, Pos. A): 4.76 mm
IC (GTC – Inscribed circle diameter, Pos. A): 9.525 mm
Insert size: 16
Shank height (H): 16
H (GTC – Shank height): 16 mm
HF (GTC – Functional height): 16 mm
Shank width (B): 20
B (GTC – Shank width): 20 mm
WF (GTC – Functional width): 20 mm
Head length (LH): 25
KAPR (GTC – Tool cutting edge angle): 95 Degree
Total length (LF/OAL): 120
LF (GTC – Functional length): 120 mm
OAL (GTC – Overall length): 120 mm
CZCMS (GTC – Connection size code machine side): 1620
Internal coolant: No
HAND (GTC – Cutting direction): R
Type: Right
MIID (GTC – Master insert identification): TNGG160408
