Super okazja Cermet Turning Insert – CCMT09T308 TN60

Opis

Opis:

Cermet Turning Insert CCMT09T308 TN60

Cecha szcz.:

RE (GTC – Corner radius): 0.8 mm
IFS (GTC – Insert mounting style code): 3
S (GTC – Insert thickness): 3.97 mm
AN (GTC – Clearance angle major): 7 Degree
Corner radius (RE): 8
IC (GTC – Inscribed circle diameter): 9.525 mm
L (GTC – Cutting edge length): 9.672 mm
EPSR (GTC – Insert included angle): 80 Degree
Size: 09T3
Description: CCMT
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Grade: TN60
