PFERD TOOLS electric edge mill EDGE FINISH UWER 18/110 EF-30 TK 230 volts 11,000-2,750 RPM/1,750 watts Rabat

Opis

Wykonanie:

• In transport case

Opis:

• Electric grinders are general all-rounders.
• They offer a high power output in relation to their size and weight.
• They are particularly suitable for use with grinding tools that require a constant rotational speed.
• Electric grinders can be used for nearly every application.
• They are used in many industries in different processes.
• The stepless electronic rotational speed control allows the use of various types of tools on one single tool drive.
• The electric grinder with stepless rotational speed regulation is particularly suitable for quick and clean work on edges.
• The on/off switch is lockable.
• The drive and its corresponding accessories can be stored in the carry case.
• 4 m power cable with mains connector, 3 keys (1x SKS SW 5 mm, 1x HS 40-42, 1x SDR TX 15K), anti-vibration handle.
• PFERD TOOLS ERGONOMICS recommends the EDGE FINISH system for work on edges as an innovative tool solution for comfortable working with reduced vibration, good haptic properties and optimized tool guidance.
• PFERD TOOLS EFFICIENCY recommends the EDGE FINISH system for work on edges for working for long periods with low levels of fatigue, whilst saving resources and achieving perfect results as quickly as possible.

Cecha szcz.:

• Power consumption: 1750 watts
• Power output: 1150 watts
• Rotational speed range, from: 2750 RPM
• Rotational speed range, to: 11000 RPM
• Version: In transport case
• Voltage, from: 230 volts
• Width, metric: 70 mm
• Length, metric: 500 mm
• Net weight: 7.36 kg
• Plug type: Contour plug
• Dia. thread: M14
• Height: 150 mm

Zaleta:

• The digital electronics enable a constant rotational speed to be maintained.
• Overload protection.
• Smooth start-up to protect people, tools and the drive.
• Restart protection in case of power failure (USP).
• Maximum comfort and optimal guidance thanks to ergonomically optimized design and very good haptic properties.

Zastosowanie:

• Recommendations for use: Move the EDGE FINISH system over the workpiece counterrotationally in order to prevent damage to the tool and chatter marks on the workpiece. Process very uneven burn burrs beforehand using reinforced grinding wheels or POLIFAN flap discs to prevent damage to the cutting inserts and improve guidance. Proper servicing and correct storage will increase the service life of your drive and tool.
