Okazja Milling Toolholder – MRW32-S32-12-3T

Opis

Opis:

Milling Toolholder MRW32-S32-12-3T

Cecha szcz.:

AN (GTC – Clearance angle major, Pos. A): 0 Degree
WT (GTC – Weight of item): 0.81 kg
CNSC (GTC – Coolant entry style code): 1
Number of inserts: 3
CXSC (GTC – Coolant exit style code): 3
ZEFF (GTC – Face effective cutting edge count): 3
S (GTC – Insert thickness, Pos. A): 4.75 mm
APMX (GTC – Depth of cut maximum): 6 mm
Insert size: 12
IC (GTC – Inscribed circle diameter, Pos. A): 12 mm
DC (GTC – Cutting diameter): 20 mm
BD (GTC – Body diameter): 30 mm
Shank diameter (DCON): 32
DCON (GTC – Connection diameter machine side): 32 mm
DCX (GTC – Cutting diameter maximum): 32 mm
LU (GTC – Usable length): 35 mm
OHX (GTC – Protruding length): 45 mm
LS (GTC – Shank length): 100 mm
Total length (OAL): 140
LF (GTC – Functional length): 140 mm
OAL (GTC – Overall length): 140 mm
CZCMS (GTC – Connection size code machine side): 320
RPMX (GTC – Rotational speed maximum): 22000 1/min
Recess (LDN): 40,0
Shank type: Cylindrical
TCDCON (GTC – ISO-tolerance class connection bore diameter machine side): h6
Diameter (DC): ø32
HAND (GTC – Cutting direction): R
MIID (GTC – Master insert identification, position A): ROMU1204M0ER-GM
BMC (GTC – Body material code): S
Internal coolant: Yes
