Opis
Wykonanie:
- High contrast digit display
- Locking screw above
- Lapped guideway
- Measuring blade for inside measurements
- Slide and beam made of hardened stainless steel
- Step measuring function
- Immediate measurements due to the Reference System
- Raised guideway for the protection of the scale
- Dirt wipers are integrated in the slide
Opis:
Digital caliper MarCal 16 ER Measuring range: 0 – 300 mm
- Digit increment mm/inch: 0.01 / .0005″
- Depth measurement:
- Data interface: USB, Opto RS-232C, Digimatic
- Friction wheel: true
- IP protection class: none
Cecha szcz.:
- Data interface: USB A
- Product type: 16 ER
- Digit increment mm/inch: 0.01 / .0005″
- Measuring range: 0 – 300 mm
- Measuring range: 0 – 12″
- Error limit inch: .0015″
- Dimension d in mm: 388 mm
- Dimension b in mm: 64 mm
- Dimension c in mm: 19 mm
- Dimension e in mm: 16 mm
- Dimension a in mm: 14 mm
- Digit height: 8.5 mm
- Error limit (mm): 0.04 mm
Norma:
ISO 13385-1
