Oferta limitowana Cermet Milling Insert – SPCN1904EETR1 TN100M

Opis

Opis:

Cermet Milling Insert SPCN1904EETR1 TN100M

Cecha szcz.:

BS (GTC – Wiper edge length): 0.7 mm
IFS (GTC – Insert mounting style code): 1
BCH (GTC – Corner chamfer length): 1.2 mm
S (GTC – Insert thickness): 4.76 mm
AN (GTC – Clearance angle major): 11 Degree
KCH (GTC – Corner chamfer angle): 15 Degree
IC (GTC – Inscribed circle diameter): 19.05 mm
L (GTC – Cutting edge length): 19.05 mm
AS (GTC – Clearance angle wiper edge): 20 Degree
KRINS (GTC – Cutting edge angle major): 75 Degree
EPSR (GTC – Insert included angle): 90 Degree
Size: 1904
TC (GTC – Tolerance class insert): C
HAND (GTC – Insert hand): R
Description: SPCN
Grade: TN100M
