Obniżka ceny Carbide Milling Insert – SDKN1203AUTN PR1210

Opis

Opis:

Carbide Milling Insert SDKN1203AUTN PR1210

Cecha szcz.:

BS (GTC – Wiper edge length): 0.5 mm
IFS (GTC – Insert mounting style code): 1
BCH (GTC – Corner chamfer length): 1.2 mm
S (GTC – Insert thickness): 3.18 mm
IC (GTC – Inscribed circle diameter): 12.7 mm
L (GTC – Cutting edge length): 12.7 mm
AN (GTC – Clearance angle major): 15 Degree
KCH (GTC – Corner chamfer angle): 45 Degree
KRINS (GTC – Cutting edge angle major): 67 Degree
EPSR (GTC – Insert included angle): 90 Degree
Size: 1203
TC (GTC – Tolerance class insert): K
HAND (GTC – Insert hand): N
Grade: PR1210
Description: SDKN
