Do wyczerpania zapasów Cermet Turning Insert – TCMT090202HQ TN60

Opis

Opis:

Cermet Turning Insert TCMT090202HQ TN60

Cecha szcz.:

RE (GTC – Corner radius): 0.2 mm
Corner radius (RE): 2
S (GTC – Insert thickness): 2.38 mm
IFS (GTC – Insert mounting style code): 3
IC (GTC – Inscribed circle diameter): 5.56 mm
AN (GTC – Clearance angle major): 7 Degree
L (GTC – Cutting edge length): 9.63 mm
EPSR (GTC – Insert included angle): 60 Degree
Size: 902
Chip breaker: HQ
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Description: TCMT
Grade: TN60
