Darmowy zwrot Carbide Turning Insert – TCGW080201 KW10

Opis

Opis:

Carbide Turning Insert TCGW080201 KW10

Cecha szcz.:

RE (GTC – Corner radius): 0.1 mm
Corner radius (RE): 1
S (GTC – Insert thickness): 2.38 mm
IFS (GTC – Insert mounting style code): 3
IC (GTC – Inscribed circle diameter): 4.76 mm
AN (GTC – Clearance angle major): 7 Degree
L (GTC – Cutting edge length): 8.244 mm
EPSR (GTC – Insert included angle): 60 Degree
Size: 802
TC (GTC – Tolerance class insert): G
Grade: KW10
HAND (GTC – Insert hand): N
Description: TCGW
