Darmowy zwrot Carbide Milling Insert – TPKN1603PDFR KW10

Opis

Opis:

Carbide Milling Insert TPKN1603PDFR KW10

Cecha szcz.:

BS (GTC – Wiper edge length): 0.7 mm
IFS (GTC – Insert mounting style code): 1
BCH (GTC – Corner chamfer length): 1.2 mm
S (GTC – Insert thickness): 3.18 mm
IC (GTC – Inscribed circle diameter): 9.525 mm
AN (GTC – Clearance angle major): 11 Degree
AS (GTC – Clearance angle wiper edge): 15 Degree
KCH (GTC – Corner chamfer angle): 30 Degree
EPSR (GTC – Insert included angle): 60 Degree
KRINS (GTC – Cutting edge angle major): 90 Degree
Size: 1603
TC (GTC – Tolerance class insert): K
Grade: KW10
HAND (GTC – Insert hand): R
Description: TPKN
