Opis
Wykonanie:
- Particularly slim extension
Opis:
- The drive is equipped with a collet tool mounting for mounted tools.
- The exhaust direction the air grinder is at the back.
- The air grinder has to be used with oil.
- The drive stands out thanks to its extended design and particularly slim extension.
- Due to the lever throttle, the drive has a dead man’s switch.
- 1 m exhaust hose and 3 m air supply hose with 1/4″ male threaded connection and threaded quick coupling (STGI), 6 mm collet (collet group 5), 2 keys (1x EM SW 7/16″, 1x EM SW 9/16″).
- PFERD TOOLS ERGONOMICS recommends the drive to improve comfort when working.
Cecha szcz.:
- Operating pressure: 6.3 bar
- PFERD TOOLS type: PGAS 8/220 VS-HV
- Power output: 600 watts
- Rotational speed: 22000 RPM
- Collet group: 5
- Throttle type: Lever
- Version: Particularly slim extension
- Width, metric: 46 mm
- Air consumption, at idle: 0.95 m³/min
- Air consumption, under load: 0.85 m³/min
- Incl. dia collet [mm]: 6 mm
- Length, metric: 335 mm
- Number of oil drops [min]: 5 drops
- Net weight: 1.17 kg
- Air supply hose internal dia.: 8.5 mm
- Exhaust direction: rear
- Height: 46 mm
Zaleta:
- The extended version of the tool is suitable for working on hard-to-reach and particularly narrow areas.
- Safe working using dead man’s switch.
- No dust turbulence on the workpiece side.
- The drive is equipped with a collet tool mounting for mounted tools.
- The exhaust direction the air grinder is at the back.
- The air grinder has to be used with oil.
- The drive stands out thanks to its extended design and particularly slim extension.
- Due to the lever throttle, the drive has a dead man’s switch.
- 1 m exhaust hose and 3 m air supply hose with 1/4″ male threaded connection and threaded quick coupling (STGI), 6 mm collet (collet group 5), 2 keys (1x EM SW 7/16″, 1x EM SW 9/16″).
- PFERD TOOLS ERGONOMICS recommends the drive to improve comfort when working.
Cecha szcz.:
- Operating pressure: 6.3 bar
- PFERD TOOLS type: PGAS 8/220 VS-HV
- Power output: 600 watts
- Rotational speed: 22000 RPM
- Collet group: 5
- Throttle type: Lever
- Version: Particularly slim extension
- Width, metric: 46 mm
- Air consumption, at idle: 0.95 m³/min
- Air consumption, under load: 0.85 m³/min
- Incl. dia collet [mm]: 6 mm
- Length, metric: 335 mm
- Number of oil drops [min]: 5 drops
- Net weight: 1.17 kg
- Air supply hose internal dia.: 8.5 mm
- Exhaust direction: rear
- Height: 46 mm
Zaleta:
- The extended version of the tool is suitable for working on hard-to-reach and particularly narrow areas.
- Safe working using dead man’s switch.
- No dust turbulence on the workpiece side.
- The extended version of the tool is suitable for working on hard-to-reach and particularly narrow areas.
- Safe working using dead man’s switch.
- No dust turbulence on the workpiece side.
