Carbide Turning Insert – TPMR160304GP CA515 Promocja

Opis

Opis:

Carbide Turning Insert TPMR160304GP CA515

Cecha szcz.:

RE (GTC – Corner radius): 0.4 mm
IFS (GTC – Insert mounting style code): 1
S (GTC – Insert thickness): 3.18 mm
Corner radius (RE): 4
IC (GTC – Inscribed circle diameter): 9.525 mm
AN (GTC – Clearance angle major): 11 Degree
L (GTC – Cutting edge length): 16.498 mm
EPSR (GTC – Insert included angle): 60 Degree
Size: 1603
Grade: CA515
COATING (GTC – Coating): CVD Coated Carbide
Chip breaker: GP
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Description: TPMR
