Carbide Turning Insert – SCMT09T304HQ CA510 Wyprzedaż

Opis

Opis:

Carbide Turning Insert SCMT09T304HQ CA510

Cecha szcz.:

RE (GTC – Corner radius): 0.4 mm
IFS (GTC – Insert mounting style code): 3
S (GTC – Insert thickness): 3.97 mm
AN (GTC – Clearance angle major): 7 Degree
IC (GTC – Inscribed circle diameter): 9.525 mm
L (GTC – Cutting edge length): 9.525 mm
EPSR (GTC – Insert included angle): 90 Degree
Size: 09T3
Grade: CA510
COATING (GTC – Coating): CVD Coated Carbide
Chip breaker: HQ
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Description: SCMT
