Carbide Turning Insert – DNMM150608PX CA515 Zamów teraz

Opis

Opis:

Carbide Turning Insert DNMM150608PX CA515

Cecha szcz.:

AN (GTC – Clearance angle major): 0 Degree
RE (GTC – Corner radius): 0.8 mm
IFS (GTC – Insert mounting style code): 2
S (GTC – Insert thickness): 6.35 mm
Corner radius (RE): 8
IC (GTC – Inscribed circle diameter): 12.7 mm
L (GTC – Cutting edge length): 15.504 mm
EPSR (GTC – Insert included angle): 55 Degree
Size: 1506
Grade: CA515
COATING (GTC – Coating): CVD Coated Carbide
Description: DNMM
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
Chip breaker: PX
