Bezpieczna płatność CBN Turning Insert – SNGA120408S04030MEH KBN05M

Opis

Opis:

CBN Turning Insert SNGA120408S04030MEH KBN05M

Cecha szcz.:

AN (GTC – Clearance angle major): 0 Degree
RE (GTC – Corner radius): 0.8 mm
LE (GTC – Cutting edge effective length): 1.8 mm
IFS (GTC – Insert mounting style code): 2
S (GTC – Insert thickness): 4.76 mm
Corner radius (RE): 8
IC (GTC – Inscribed circle diameter): 12.7 mm
L (GTC – Cutting edge length): 12.7 mm
EPSR (GTC – Insert included angle): 90 Degree
Size: 1204
TCE (GTC – Tipped cutting edge code): B
TC (GTC – Tolerance class insert): G
Grade: KBN05M
COATING (GTC – Coating): MEGACOAT CBN
HAND (GTC – Insert hand): N
Description: SNGA
