Opis
Wykonanie:
- Excellent readability thanks to combined display:
– bar graph for dynamic path information
– digital display for exact readings
- Can be controlled independently of a machine tool
- Large working range in all axes (X, Y, Z) prevents damage to the stylus by contacting errors
- Compact metal housing and long probe arm
- Shockproof movement
Opis:
– bar graph for dynamic path information
– digital display for exact readings
Digital 3D edge finder MarTest 802 EW
- Working ranges X, Y,Z -axis: – 2 to 4 mm
- igit_step_mm: 0.005
Scope of delivery: Battery, operating instructions, measuring insert 802 EWt
Cecha szcz.:
- Calibration type: Uncalibrated
- function: ON/OFF
- Product group name: MarTest
- IP Protection class: IP 65
- Product group name: Lever gauges and edge finders
- Application: Used in milling and eroding machines for; zero point determination on workpieces Determination of bore centers Determination and correction of workpiece alignment ; ; and for measuring; lengths Depths
- Product name: Digital 3D edge finder
- Battery type: CR 2032 (3V Lithium)
- function: Auto OFF after 2 h
- Product type: 802 EW
- Repeat accuracy at zero point, unidirectional: ± 0.005 mm
- Display range: +/-2 mm
- Working ranges X, Y, Z axis: – 2 to 4 mm
- Clamping shaft (mm): 16 mm
Norma:
Factory standard
